This report outlines the installation procedure for a glass railing system supported by a top-mounted stainless steel spigot. It includes various installation options for both wood and concrete substrates.
The dimensions for the spigots are derived from reports provided by R.F. Transparent, specifically "Canadian Building Envelope Science and Technology" reports L23-1577-6770a-r1 and L23-1577-6770b. The bolted connections have been designed to meet the specified design load for the spigots and glass railing.
Additionally, the recommended configuration of spigots based on the width of the railing is as follows: for widths of 6” to 15”, one spigot is required; for widths of 15” to 72.8”, two spigots are needed; and for widths of 72.8” to 100”, three spigots are necessary.
Glass Railing Hardware Warranty:
Our hardware is crafted from marine-grade stainless steel 2205, designed to resist rust in even the harshest conditions. We proudly offer a 10-year no-rust promise, guaranteeing that our hardware will remain rust-free. Whether you live near saltwater or in highly corrosive environments, our 10-year warranty will always stand.
Tempered Glass Warranty:
We guarantee that our glass products are free from manufacturing defects, such as air bubbles, and will arrive at your doorstep in perfect condition. Our team meticulously inspects and packs each piece of glass to ensure it meets our high standards for quality and safety.
Our Commitment:
- Marine-Grade Stainless Steel Hardware: 10-year no-rust guarantee.
- Glass Products: Assurance of no manufacturing defects and safe delivery.
Our team is dedicated to craftsmanship and safety, ensuring that every product you receive meets our stringent quality standards. If you encounter any issues, please contact our customer service team, and we will address your concerns promptly.
